When it comes to top-quality refueling transfer tanks, trust in JME's expertise and excellence. Our 110 Gallon Powder Coated Fuel Transfer Tank is DOT approved and backed by a Special Permit from the U.S. Department of Transportation, ensuring legal manufacture, marking, and selling of these high-quality aluminum refueling transfer tanks. Whether you're in commercial, state, or private applications, these tanks are built to withstand the toughest conditions and offer peace of mind with their superior construction.
Note: DOT Certified for Gasoline, Diesel, Methanol, Kerosene, Aviation fuel and other liquids
Features
- Multi-Fuel Compatibility: This tank is suitable for a wide range of fuels, including gas, diesel, methanol, kerosene, and aviation fuel.
- Lockable Vent/Prevent Filler Cap: Equipped with a commercial-grade lockable vent/prevent filler cap, providing security.
- Fully Baffled Design: Features a fully baffled interior to reduce the movement of contents during transportation, ensuring stability.
- Reinforced Bungs: Two 2 in. NPT reinforced bungs, providing superior strength and compatibility with various fueling systems.
- Drain Port: Includes a 3/8 in. NPT drain for easy and convenient tank drainage when needed.
- Hold Down Brackets: Designed with hold-down brackets for secure mounting and stability during transport.
- Pressure Leak Detection Test: Prior to shipment, each tank undergoes a pressure leak detection test to ensure it is free from defects.
- Clean and Debris-Free: Our tanks are cleaned both inside and outside, ensuring they are free from debris and contaminants.
- 1-Year Limited Warranty: For added peace of mind, the manufacturer provides a 1-year limited warranty on this fuel transfer tank.
- DOT Certified Special Permit Issued: Our 110 Gallon Fuel Transfer Tank comes with a Special Permit issued by the U.S. Department of Transportation (DOT), ensuring its safety and compliance with regulations.
Specifications
- Capacity: 110 Gallons
- Material: Aluminum
- Cap Type: Vent/Prevent Filler Cap
- Bungs: Two 2 in. NPT Reinforced Bungs
- Drain Port: 3/8 in. NPT
- Dimensions: 23 1/2 in. x 48 1/2 in. x 24 in.
Notes:
- Mounting tabs extend out 1-1/2 in.
- Add 2-1/2 in. for cap height
- Pumps with aluminum threads must be coated with Anti-Seize prior to installation. Do not dry fit. Do not use teflon tape or pipe dope.
- Do not install a pump over 30 lbs. to a standard duty tank. For pumps over 30 lbs., a Severe Series tank must be used.
- This tank must be grounded to your vehicle. Metal to metal contact between mounting hardware and truck bed or running a ground wire to one of the mounting bolts.
* The 30 lb. limit includes pump and any other accessories such as filter kit, meters, etc. Failure to follow these guidelines will result in voiding your warranty. Do not install riser between the fuel tank fitting and the pump.
