The TS30AV04AGCBMXAXX is a 100% non-ferrous 5-digit mechanical Standard Fuels transfer meter. This meter is equipped with 3" NPT threads and is designed to register 40-300 gallons per minute at 0.05% repeatability.
Fill-Rite's TS30 Mechanical Series of oval gear fuel transfer meters are ideal for high-volume custody transfer applications, registering with a 5-digit resettable counter and an 8-digit totalizer. Fill-Rite Oval Gear Meters utilize positive displacement (PD) technology due to its elite performance across a wide range of fluid viscosities. Positive displacement technology affords low pressure loss across the meter chamber and minimum slippage, ultimately yielding a very high degree of accuracy and linearity over the life of the meter.
The TS Series is well suited for use in fuels process / transfer, high speed batching and loading, tank truck meters, LPG systems, stationary dispensing, industrial and petrochemical refining / processing. Combined with a mechanical register, printer, or solenoid batching, it is possible to build an application specific system that delivers performance, accuracy, and easy maintenance making the TS Series the intelligent choice.
The Aluminum TS Series offers a full range of metering options ranging from 1", 1-1/2", 2", and 3" sizes with 40-300 GPM at a 150 PSI. These highly precise meters are available in a wide range of configurations to accommodate different temperatures, viscosities, chemical compatibilities, mechanical register calibrations, strainers, filters, air eliminators, air check, back pressure, and preset valves, flanges, and seals.
Although no flow meter is ideal for ALL operating conditions, Fill-Rite positive displacement meters offer the following advantages:
- No straight pipe requirements on the flow meter inlet and outlet
- Weights and Measures Approved for custody-transfer in the US, Canada, EU, and Australia
- Easily maintained over the life of the meter due to minimal moving parts
- Excellent accuracy and linearity
- Adaptable to a multitude of accessories like registers, strainers, and air eliminators
- Required pump horsepower is lower than other meter technologies, resulting in lower initial system costs and long-term operating costs
Features
- Weights and Measures Certified with NTEP Certificate
- Precision Engineering: The Fill-Rite oval gear flow meter is crafted with precision engineering, ensuring accurate and repeatable measurements. It excels in providing dependable data for custody transfer, giving you confidence in your transactional processes.
- Wide Application Range: The versatility of oval gear technology makes it suitable for measuring a wide range of viscosities. These meters are compatible with fluids used in the chemical, pharmaceutical, food and beverage, and petroleum industries.
- Robust Construction: Built to withstand the harshest environments, the anodized aluminum body of this meter boasts a robust construction that ensures durability and longevity.
- High Accuracy: Designed to minimize uncertainties in measurement, making it a trustworthy instrument for custody transfer applications where precision is paramount.
- Easy Installation and Maintenance: Save time and resources with our user-friendly design. The installation process is straightforward, and routine maintenance is a breeze, ensuring minimal downtime for your operations.
- Compliance: The Fill-Rite oval gear flow meter meets industry standards and compliances for custody transfer applications, providing peace of mind when it comes to regulatory requirements.
- Cost Efficiency: By investing in Fill-Rite's custody transfer flow meter, you are making a cost-effective choice. Its longevity, low maintenance requirements, and high accuracy contribute to overall cost savings.
- Reliable Data for Transactions: Trust is essential in custody transfer transactions, and our flow meter provides the reliability you need. Eliminate uncertainties and ensure fair and accurate transactions every time.
- Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently.
Specifications
- Max Flow:
- TS15A: 60 GPM
- TS20A: 150 GPM
- TS30A: 300 GPM
- Max Pressure: 150 PSI (10 BAR)
- Register Type: 5 Wheel Mechanical
- Material: Aluminum
- Seal Material: Viton
- Strainer (optional): 40 Mesh
- Rotor/Bearings Material: Polyphenylene sulfide (PPS)/Carbon
- Operating Temperature Range: -40 - 180°F / -40 - 82°C
- Totalizer Digits: 8
- Meter Accuracy: Meets NCWM/NTEP requirements
- Viscosity Range (cSt): Up to 300 - can be used with higher viscosities, meter will be derated
- Certifications: NCWM/NTEP, UL
