Kuriyama T450LL is a white food suction & discharge hose designed to transfer liquid, fatty, oily food and alcoholic beverages (max 75 proof). Roll length is 100'. Not recommended for abrasive materials. All hoses are assembled with 316 stainless steel sanitary style clamp ends that are crimped on both ends. Please contact us for pricing on additional hose assembly options.
Service Temperature Range: -22°F (-30°C) to 176°F (+80°C)
NOTE: Hose may be sterilized with 5% soda solution. Not recommended for dry abrasive materials.
Features
- Comes fully assembled with 316 stainless steel triclamp fittings
- Designed for liquid, fatt, oily food and alcoholic beverage (max 75 proof) suction and discharge
- Made with FDA approved materials
- May be sterilized with 5% soda solution
- Not recommended for dry abrasive materials
Specifications
- Cover: White NBR/PVC ? abrasion, ozone and oil resistant
- Reinforcement: Spiraled high tensile textile cords, and 4 highly flexible steel helix wires
- Tube: White NBR
- Branding: ALFAGOMMA® ITALY T405 10 BAR (150 PSI) GENERAL PURPOSE FOOD QUALITY S & D (black letters)
- 304 stainless steel ferrules
- 316 stainless steel triclamp ends
- Working Pressure: 150 PSI
- Temperature Range: -22°F (-30°C) to 176°F (+80°C)
- Vacuum HG: 30 in (3"" ID = 27 inHG)
- FDA and 3A approved
Food Guide
- Food grade liquids such as potable water, beer, wine and juice (max 75 proof)
- Ice transfer
- Milk and dairy product transfer
- Water suction - standard duty
